CP68

Elegance, Comfort and Safety

The new CP68 system for windows and sliding doors combines elegance and performance with security.
This sliding system has characteristics that make it unique, such as narrow profiles that allow the integration of large windows and doors for maximum light entry, reaching the RC2 class in theft resistance.
The innovative integrated technology guarantees the best technical and thermal performance on the market.

This system offers total creative freedom to those looking to create contemporary spaces, with maximum comfort and security.

SKU: CP68 - Reynaers Categories: , Product ID: 2119

FLEXIBILITY ABOVE ALL
This sliding system offers a wide range of leaf types, possibility of embedding, option of 2 or
3-rail and opening up to 6 sheets.

Visible hitch width: 34 mm
Maximum sheet height: 2500 mm
Minimum sheet height: 1500 mm
Minimum glass thickness: 28 mm
Maximum glass thickness: 36 mm

Comfort

  • Air permeability, max. test: 4 (600 Pa)
  • Water tightness: 7B (300 Pa)
  • Wind load resistance: B4 (1600 Pa)
  • Acoustic performance: Rw (C; Ctr) = 31 (-1;-5) / 38 (-2;-5) dB

Safety

  • Intrusion resistance: RC2/WK2

Energy

  • Thermal insulation (Uf): 2.51 W/m²K
