CONSTRUCTIVE SOLUTIONS
• Fixed rim: single, double or triple rail;
• Assembly of the profiles in right cut or half-square;
• One to six sheets with the possibility of immobilizing one of them;
• Optional: finishing profiles for rehabilitation works.
SIZING
Movable sheets:
400 mm < height < 3000 mm
400 mm < width < 3000 mm
maximum leaf area: 6m2
HARDWARE
• Maximum weight per sheet: 200 Kg (base solution);
• Extra option: 300 Kg;
• Closing: multi-point triggered by cremone or built-in.
Lift solution
• Maximum weight per sheet: 350 Kg.
GLAZING CAPACITY
Height = [400;3000] mm
Width = [400;3000] mm
